SHANGHAI MOOHA IMPORT & EXPORT CO.,LTD.
0086-15800592188
 |
| Quantity: | |
|---|---|
MH-32E
84172000
201 Stainless Steel Economic Type 32 Pans Electric Gas Diesel Oil Rotary Oven Bread Cake Cookies Meat Duck Baking Machine
Parameter
| Item-No. | MH-32E(electric) | MH-32G(gas) | MH-32D(diesel) |
| specified voltage | ~3N380V/50Hz | ~3N380V/50Hz | ~3N380V/50Hz |
| fuel consumption | 48kw | Natural gas(3.1-3.7)M3/h LPG(2.2-3.4)M3/h (3L)(reference) | 4L /h |
| drive power | 2.5kw | 2.5kw/h | 2.5kw |
| temperature range | room temperature-400ºC | room temperature-400ºC | room temperature-400ºC |
| production | 100kg/h(e.g:bread) | 100kg/h(e.g:bread) | 100kg/h(e.g:bread) |
| Trolley size | 820*670*1700mm | 820*670*1700mm | 820*670*1700mm |
| Trolley layers | 16 layers×2=32tray | 16 layers×2=32tray | 16 layers×2=32tray |
| overall size | 2000*1800*2200mm | 2000*1800*2200mm | 2000*1800*2200mm |
| pacakge size | 2100*1900*2400mm | 2100*1900*2400mm | 2100*1900*2400mm |
| net weight | 1300kg | 1300kg | 1300kg |
| material | stainless steel | stainless steel | stainless steel |
| Tray dimension | 400*600mm | 400*600mm | 400*600mm |
Features
1. Large baking capacity, different models 64 trays, 32 trays and 16 trays avilable
2. The rotary oven adopts an all-stainless steel body, and the tuyere is made of 2mm stainless steel to ensure the hardness of the tuyere, not easy to deform, and baking more evenly
3. The motor used in the rotary furnace adopts a 30-year-old brand motor, and the quality is guaranteed
4. There are three types of rotary ovens: oil, gas, and electricity. The oil and gas use Italian burners(Bultur brand), high efficiency and low fuel consumption;
5. The electric rotary furnace uses stainless steel heating tubes, and far-infrared heating tubes are optional, suitable for baking cakes and traditional products
6. Our rotary oven adopts 3 channels and 5 stages to adjust the tuyere, which is easier to adjust the baking effect
7. Adopt a humanized design with an alarm device, especially when multiple ovens are baking together, you can see at a glance which oven has finished baking!
8. Widely baking range, which can bake moon cakes, bread, pastries, biscuits, egg yolk pie, burgers, oatmeal, toast and meat, such as roast chicken, roast duck, roast goose, pork jerky, beef jerky, dried shrimp, etc.
More details of machine
