Multifunction Granule Powder Pouch Packing Machine Customization Accepted for chocolate coffee bean / milk protein / chili sauce ketchup jam

Automatic Potato Chips Production Line Popcorn Snack Bag Packing Machine Frozen French Fries Making Machine Customization Accepted for chocolate coffee bean / milk protein / chili sauce ketchup jam
Voltage:
Dimension(L*W*H)::
Raw material:
Custom requirements:
Packing speed:
Availability:
Quantity:
  • MQ-420
  • mooha
model
MQD-420
MQD-530
MQD-720
Bag size
L80-300mm
W80-200mm
L100-350mm
W100-250mm
L120-450mm
W120-350mm
Packing speed
25-80bags/min
25-70bags/min
25-60bags/min
power
AC220V, 50-60Hz, 3.0KW
AC220V, 50-60Hz, 5.0KW
AC220V, 50-60Hz, 6.0KW
Compressed air cost
6-8kg/m2,0.15m3/min
6-8kg/m2,0.25m3/min
6-8kg/m2,0.35m3/min
Total weight
500kg
700kg
800kg
Outline dimension
L1650×W1300×H1700mm
L1600×W1150×H1800mm
L1800×W1550×H1900mm

Main characteristic:

1. Use intelligent temperature controlling machine to have accurate temperature control, ensure the artistic and neat seat.
2. Use PLC control servo double-pull and single pull membrane, structure, super touch screen structure drives the control center, maximize the whole machine’s control precision, reliability and intelligentized level.
3. This machine completes the whole packing procedure of measuring, loading materials, bagging, date printing, charging and products transporting automatically as well as counting.
4. Have error indicating system, helping handle the trouble immediately.
5. Make block bags and hanging bags according to customer’s different requires.

Selected installations:

Suitable for many kinds of measuring equipments, and package different kinds of products; such as puffy food, shrimp roll, peanut, popcorn, cornmeal, seed and sugar etc. which shape is roll, slice and granule.

usage:

Suitable for automatic packing of popped food , fruit, candy, biscuit, deep frozen food, melon seeds, roasted nut, pips and other granule materials.

Suitable packing materials:

OPP/PE,PET/VM,PET/PE,OPP/CPP and compound heat sealing materians.

packing machine 420 (3)packing machine 420 (1)packing machine 420 (3)packing machine 420 (1)packing machine 420 (4)
